Product Name
|
10/100Mbps Industrial POE Fiber Switch (2F+6TP)
|
|
Model No.
|
IM-FP266FE
|
|
Port
|
2 x 100Mpbs SFP ports
SM：1310nm/1550nm，20Km
1490nm/1550nm，40~120Km
MM：1310nm，2Km
6x10/100M UTP RJ45（Support MDI/MDIX auto-sensing）
|
|
Switching features
|
Transmission mode：storage and forward
System bandwidth：40Gbps (non-traffic jam)
|
|
Network media
|
10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)
100BASE-TX: CAT5 or above shielded twisted pair(≤100m)
SFP port，transmission distance: 20Km，40Km，60Km，80Km，100Km
|
|
LEDs
|
Power, network, fiber
|
|
Power supply
|
POE power supply input voltage: 48V (max 52V),
Single PoE power supply output power: 15.4W (port 1~6)
(802.3at standards required special instructions)
|
|
Environment
|
Working temperature：-40°～ 85°C
Storage temperature：-40°～ 85°C
Working humidity：10%～90%，non-condensing
Storage humidity：10%～95%，non-condensing
|
|
Industry Standards
|
EMI：FCC Part 15 Subpart B Class A，EN 55022 Class A
EMS：EN 61000-4-2 (ESD) Level 3，EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3，EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3，EN 61000-4-8
Traffic Control：NEMA-TS2
Vibration：IEC 60068-2-6
Freefall：IEC 60068-2-32
Shock：IEC 60068-2-27
Rail Traffic：EN 50121-4
|
|
Safety
|
CE Mark ,commercial
CE/LVD EN60950
|
|
Mechanical information
|
Shell：Corrugated metal shell
Safety class：IP44
Dimension：158 x 114.8 x 60mm
Mounting method：Din-rail mounting
|
|
Warranty
|
Replacement within 1 year; 5 years repairing
|
