SFP+ 10G SR
SFP+ 10G SR
SFP+ 10G SR

SFP+ 10G Dual fiber 1310nm 300m LC DDM

OSPLXG03D
OLYCOM's OSPLXG03D is a very compact 10Gb/s optical transceiver module for serial optical communication applications at 10Gb/s. The high speed 10Gb/s electrical interface is fully compliant with SFI specification. The high performance 850nm VCSEL transmitter and high sensitivity PIN receiver provide superior performance for Ethernet applications at up to 300m links. The SFP+ Module compliants with SFF-8431, SFF-8432 and IEEE 802.3ae 10GBASE-SR. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472. The fully SFP compliant form factor provides hot pluggability, easy optical port upgrades and low EMI emission.
Quantity
Contact Now

1. Supports 9.95 to 11.3Gb/s bit rates

2. Hot-Pluggable

3. Duplex LC connector

4. 850nm VCSEL transmitter, PIN photo-detector

5. MMF links up to 300m

6. 2-wire interface for management specifications compliant with SFF 8472 digital diagnostic monitoring interface

7. Power Supply :+3.3V

8. Power consumption<1W

9. Temperature Range: 0~ 70°C

10. RoHS compliant
