Case Study: Optical Bypass switch Optimization for Optical Communication System Protection
Project Background
In industrial optical communication systems, maintaining stable signal transmission during equipment reboot or power interruption is critical. A customer from the network communication industry required a customized Optical Bypass solution that could support automatic optical path protection during device restart and recovery processes.
The standard Optical Bypass switch configuration could not fully match the customer's operational timing requirements, especially in systems where connected devices required different reboot durations before normal communication could resume.
To solve this issue, the customer requested two key modifications:
- Built-in AC power supply integration
- Adjustable DIP switch delay control from 1 to 8 minutes
This customized solution was designed specifically for optical communication protection systems, redundant fiber networks, and industrial communication environments.
Customer Requirements
The customer’s optical communication equipment had different restart times after power recovery. If the optical path switched back too early, the connected devices might not complete initialization, which could lead to unstable communication or temporary signal interruption.
Therefore, the customer needed:
Customized Optical Bypass switch Solution
Based on the customer's application requirements, the Optical Bypass system was modified with an integrated AC power supply design and configurable DIP switch delay settings.
1. Built-in AC Power Supply
The customized version supports direct AC input, eliminating the need for external power adapters in industrial cabinets.
Benefits include:
- Simplified wiring
- Reduced installation complexity
- Improved cabinet integration
- Better suitability for industrial environments
The Optical Bypass Switch supports:
- 110–220VAC input
- Industrial terminal block connection
- DIN rail mounting installation
This design is suitable for industrial optical communication systems where stable power integration is required.
2. Adjustable DIP Switch Delay Function (1–8 Minutes)
A configurable DIP switch delay mechanism was added to support different reboot times of connected communication devices.
The delay settings allow the optical bypass switch to remain in bypass mode temporarily after power recovery, ensuring that connected devices can fully restart before switching the optical path back to normal operation.
Available delay settings:
- 1 minute
- 2 minutes
- 3 minutes
- 4 minutes
- 5 minutes
- 6 minutes
- 7 minutes
- 8 minutes
This function is especially useful in:
- Industrial Ethernet systems
- Optical transmission equipment
- Fiber communication gateways
- Redundant network systems
- Ring network protection applications
Technical Advantages
Low Insertion Loss
The optical bypass switch features typical insertion loss as low as 0.6 dB, helping reduce optical signal attenuation in high-density communication systems.
Fast Optical Switching
Switching time ≤10 ms supports rapid optical path protection and failover applications.
Long Service Life
The optical switching module supports a service life exceeding 100 million switching cycles, suitable for long-term industrial operation.
Industrial Temperature Range
Operating temperature range: -20°C to +70°C
Suitable for industrial communication cabinets and control systems.
Application Scenarios
The customized optical bypass switch solution is suitable for:
- Optical communication systems
- Industrial fiber networks
- Telecom infrastructure
- Redundant optical transmission systems
- Ring network protection
- Fiber optic testing systems
- High-density optical communication cabinets
It is particularly useful in applications where communication devices require delayed optical recovery after reboot.
Why Adjustable Delay Matters in Fiber Protection Systems
In many industrial optical networks, communication devices such as switches, gateways, or transmission equipment may require several minutes to complete initialization after power restoration.
Without delay protection:
- Optical links may recover too early
- Devices may fail to synchronize properly
- Temporary communication interruption may occur
- System stability may be affected
By adding adjustable delay control through DIP switches, the optical bypass switch can better match real industrial startup conditions and improve communication reliability.
